Solar Power Simulator power supply unit

Solar Power Simulator power supply unit
For simulating PV power to feed the PV trainer

Item No.: 105885
Add to wish list

Solar power simulator power supply unit:

Laboratory power supply unit for simulating PV power to feed the PV trainer, as a supplement or as a space-saving alternative to the mobile PV modules (Item-No.: 104447 and 105884).

The power supply unit can be used to simulate PV power approximately. This allows the PV trainer to be used flexibly as a power source for the PV trainer. We recommend operating the PV trainer primarily with PV modules (mobile PV module systems) and using the power supply unit as a flexible supplement.

  • Adjustment range: 0...300 volts (DC) / 0...4 A
  • Voltage and current control, short-circuit proof
  • Ua-adjustment via coarse and fine control
  • Ia-adjustment via coarse and fine control
  • Input voltage: 230 VAC 50-60 Hz
  • Input/output separation galvanically isolated, earth-free, ground-free
  • Output voltage: 0... 300 V (DC)
  • Output current, short-term: 0... 4 A
  • Output current, continuous: 0-3.6 A
  • Continuous output power: 1,080 W
  • Short-term load capacity 1,200 W
  • Dimensions W x H x D: approx. 451 x 134 x 410 mm
  • Weight: approx. 31 kg
